Total length 15.40 m

Hull length: 14.85 m

Length at waterline 13.54 m

Displacement approx. 14.0 t

Ballast approx. 4,000 kg

Engine: 53 kW/72 hp - turbo charged changed in 2025

Water tank approx. 650 l

Fuel tank: approx.: 300 l

CE Certificate: A (ocean).

No. Cabins: 4

No. Berths: 7

No. Bathrooms/Heads: 2

Mast length above waterline approx. 22.10 m.

Sailing rig:

Total area approx. 129 m.

Grotto approx. 67.50 m.

Automatic staysail: approx. 51.5 m.

Rigging: 119.55 m, J 5.85 m, R 18.35 m, E. 6. 15 m

Design: judel / Vrolijk & co. Interior. Hanse Yachts Design



Private boat, never used in charter! Only one owner since new.



Frame

Case white

double dark grey waterline

options: case color options according to the Hanse color palette

isophthalic gelcoat

sandwich (Balsa) above the waterline

Internal laminate bonded with polyester (orthophtalic or DCPD) the main bulkhead is laminated to the hull and deck

GRP reinforcement throughout the body

horizontal portholes in the hull



Deck:

white deck with anti-slip pad

isophthalic gelcoat vinylester top layer

Internal laminate bonded with polyester (orthophtalic or DCPD)

Sandwich construction (Balsa)



Steering system

dual control system

2 steering wheels in leather braid

rudder balancer cushion with self-aligning needle bearing

Emergency tiller



Keel

standard T-shaped, iron keel, draft 2.38 m

keel fastening: stainless steel bolts through



Deck equipment

Teak on the cockpit deck. Teak flooring on the cockpit floor, partially molded non-slip coating on the cabin roof and along the deck edges

engine control at the steering console on the starboard side

4 retractable mooring cleats

Self-standing anchor locker with electric windlass on deck Fixed anchor sleeve with anchor roller, integrated teak step and socket for genaker

Stainless steel cockpit table with teak top and plotter bracket

Sail storage locker with ladder on forepeak with large hatch

aft shower (cold and hot)

self-draining cockpit

halyard storage boxes in cockpit

storage space for gas cylinders, self-draining, in the garage compartment

stainless steel bathing ladder

Designated space for life raft

Outboard swim platform with integrated automatic jib control, fully deck mounted

Self-contained jib track, fully integrated into the bow

boom guy with 2 vertical blocks

2 x 5 Deck Rope/Organization Kit

10 deck stoppers

6 sockets for gennaker, staysail

13 deck hatches

2 opening portholes

4 opening side windows on the roof of the wheelhouse

Stainless steel stern rail with LED navigation lights and flagpole socket

stainless steel bow pulpit with LED navigation lights

stainless steel conical posts

gates in a fence

4 winches in cockpit, 2x main 55 AST EVO, 2x auxiliary 55 AST EVO



Technical systems / Water supply / Fresh water tank

fresh water tanks, capacity about 650 l (2 tanks)

the neck for the water inlet on the deck

Hot water

20L engine driven boiler and immersion 230V



Bilge pumps.

Bilge pumps

1 manual bilge pump

1 electric bilge pumps with automatic switch



Latrine/Showers

2 pumpable marine toilets

2 tanks 35 A with drain into the sea and for pumping through a neck on the deck for each toilet



Engine

Volvo D2 75 /53 kW / 72 HP, diesel, "Sail drive" mechanism, 3-blade propeller, fixed

2 diesel tanks, total capacity about 300 l

Deck filler neck, diesel filter/water separator

Soundproofing and lighting of the engine compartment with space (optional) for the generator above the engine



Electrical system

12V and 110V/230V Country Version Europe / Australia

Battery packs

main battery switch

Starter battery 12V/90Ah

service battery 2 x 12V/2x165A

Charger / Shore Power

230V shore power socket with residual current circuit breaker and 12V/50Amp charger supply system

Electrical panel 110V/230V

breaker

control sensors

voltmeter

Electrical panel 12V

switches for the entire electrical system on board (upgraded instrument panel)

voltmeter

water/fuel wastewater flow meter

12V electrical equipment

Electric windlass, pumps, LED navigation lights, interior lighting, refrigerator

230 V sockets

at the chart table, in the forward cabin (one each), in the aft cabin (one each), in the galley (double), in the saloon (double), in the heads (one each)

12V sockets

at the chart table, at the steering console

Interior lighting

overhead lighting in cabins, saloon, galley and heads

lighting in the engine compartment

reading lights in the salon and in the cabinN

Internal lighting in the aisle



Navigation lights

LED navigation lights on bow and stern pulpit, LED running lights, LED anchor lights



Navigation instruments

B&G Triton multi-function display on steering pedestal includes triducer (speed, depth, temperature)

2 illuminated compasses at the steering console

echo sounder and log



Galley

durable worktop, black quartz with integrated double sink

3-burner LPG stove with oven and gimbal

hood

LPG gas system

2 bottle storage spaces in garage compartment

Double compartment refrigerator, capacity about 140 z

Cabinets and drawers

trash can



Internal structure, interiors

Finished in high quality marine plywood, mahogany style, satin polish, maple wood option cherry wood easy Italian oak, satin polish and mahogany style

white bulkheads

wooden door frames

wooden/sandwich doors

Maple wood flooring that opens in sections.

Upholstery

Forespoke cabin

layout A1 sail storage area on the forepeak with gangway and large hatch



Bow cabin

Layout B1: Owner's cabin with island bed, spacious hanging cabinets and drawers, separate toilet and separate shower, 2 reading lamps, mirror.



Salon

layout C1, large table in the salon, cabinets,

1-size sofa on the starboard side, with a fixed table for storing wine

spacious kitchen along the hull on the left side

multifunctional central part, with TV lift, with storage space and double seat, shelves and cabinets along the body, 2 reading lamps on the bulkhead

Options within the Hanse Individual Cabin Concept

table in the saloon, 2 hatches, 4 portholes in the upper part of the wheelhouse

On the left side there is a multifunctional storage room next to the kitchen. Under the deck there is space for storing canisters

Chart table

cabinet near the chart table with a table for tools and books

space for mounting electronics

230 V/12 V socket, storage space in chart table

Lighting, storage cabinet near the chart table with shelves



Aft cabin

Layout D12 double aft cabins with storage space



Latrine/showers

separate toilet and separate shower in the forward cabin

toilet and shower in aft cabin with pump toilet

sink with mixer

electric drain pump

mirror

cabinet and shelves

opening hatch



Standing and running rigging

anodized, silver plated mast, with 2 levels of spreaders, tapered boom track with 2 vertical blocks

cruising sail set

grotto on through battens

automatic jib

boom with 2 lines of ribbing

Furling system for jib below deck - new jib 2024

mainsail halyard

false starboard

the scotch stuck

boom

backstay



Additional equipment:

Connection piece between Bimini & Sprayhood

Boom brake 1 pc

Leather upholstery 'Portofino' (Chocolate)

Teak on side decks

Teak on coachroof & halyard lids

Sun bed cushions on coachroof according to colour selection light Grey

Gangway, folding, 220 cm, with bag

Fridge unit for cockpit table XC3003 810,



The yacht is registered under the US flag. EU VAT NOT PAID.
