Dealer Information Gilman Yachts is the AvA appointed dealer for AvA Shipyard of Antalya, Turkey for North and South America and the outlying islands. Having finished a 110’ Kando series at the shipyard, we offer experience with the brand, the shipyard and the ownership of the yard. Projects are delivered at very favorable price FOB Antalya and built to suit the electrical requirements of the buyer. Completion time on KANDO 90 is 20 months from contract signing.
KANDO 90 Walkthrough Boarding the Kando 90 is via her portside passerelle or the swim platform if on a floating dock. Up six steps is an ample size Aft Deck with both fixed and loose seating around a dining table. The Salon next forward has a couch to starboard and two chairs to port. Next forward is an eight-place dining table. Forward to starboard is a Day Head and the entrance to the full beam On-Deck Master Cabin with a large Head with two basins, toilet, bidet shower and a spa tub. From the dining area forward to port is a large Galley and private stairs to a captain's cabin on the lower level all the way forward. This cabin has a walkaround berth on centerline and a large Head and walk-in closet. Back on the Main Deck in the entry foyer steps lead down to the four guest suites. Aft are matching walk-around queen berths with full Heads. Forward are matching double berth suites with full Heads. Back to the entry lobby steps lead above to the Skylounge Deck. All the way forward is a large Pilothouse with a centerline Helm and guest seating aft to stbd. The full beam Skylounge has a walk behind bar with four stools and going aft two sofas facing inboard with occasional chairs aft. A Day Head is located forward on the starboard side. The boat deck has plenty of room for outdoor seating forward of the tender. Also on the boat deck are steps to the Flybridge. The Flybridge has an upper Helm on centerline, a walk behind bar to port and a large dining area to starboard. Aft is a large sunbed area for several people. A large FRP hardtop covers much of the Flybridge.
Boat's Characteristics
Displacement Hull Form Unsinkable Hull on Flooding Water in any Compartment Minimum 2.10 m Free Height in Cabins 4x Control Stations including 2 Helm Bridges with Emergency Stop Buttons
Structural Materials Hull: High Tensile Marine Steel AH36 Superstructure: Aluminum Alloy Almg 5083 H321 Hardtop: Sandwich System Epoxy Composite Fresh Water System: Polypropylene Pipes Sanitary System: PVC Pipes Fuel System: Mild Steel Pipes Sea Water Cooling System: CuNiFe Pipes Fire Extinguishing System: Galvanized Steel Pipes Bilge Suction System: Galvanized Steel Pipes Tank Air Vent System: Galvanized Steel Pipes Hydraulic System: Seamless Steel Pipes Stainless Steel Equipment: AISI316L unless otherwise specified
Engines, Propulsion System, Speed & Range Main Engines: VOLVO-PENTA D13's • 2x 450 HP @2250 RPM Heavy Duty Marine Engines 2x Gearbox: TWINDISK or ZF Propulsion System: Long Shaft & Fixed Blade Propellers: • AISI316L Stainless Steel Propeller Shafts Max Speed: 13-14 Knots (95% Engine Load) Cruise Speed: 8-10 Knots (60% Engine Load) Cruise Range: 5,200+ Nautical Miles at Cruise Speed
Maneuvering, Steering & Mooring 4x Control Stations:
1x Wheelhouse, 1x Flybridge, 2x at Wings
4x Dual Electronic Main Engine Throttles: VOLVO-PENTA 1x Steering Gear: HIDROMARIN or DATA:
Electro-Hydraulic Steering Gear Pump Actuated Cylinders Manual Operation Ability on Emergency Incorporated with rudder angle indicator and auto pilot system
700 kg-f, Hydraulic operated a bow thruster actuated by central hydraulic power unit
2x Anchor Winch: HIDROMARIN or DATA:
Hydraulic Operated and made of Stainless Steel AISI316L Anchor Winch connected to the central hydraulic power unit in the Engine Room. Joystick on Control Stations Two, polished stainless steel AISI316L chain locks
2x Mooring Capstans: HIDROMARIN or DATA: Hydraulic Operated through Central Power Unit
Polished Stainless Steel AISI316L & Raised Position with foot buttons
2x Anchors: INHOUSE:
Galvanized Steel, High Holding Type, 1x 270 Kg, 1x 190 Kg, Seated at Port and Starboard Side
Chain:
18 mm, Grade II, total 255 m galvanized steel chain for each anchor incorporated with a digital chain meter goes through 2 x S.S. AISI304 hawse pipes Composite covered chain locker with sea water flush system, drains overboard
10x Bollards: INHOUSE:
Highest Quality Polished Stainless Steel AISI316L, welded to the raised deck position 4x Large Size at the Fore Deck, 2x Large Size at the aft Main Deck, 2x Small Size at the Middle Main Deck, 2x Small Size at the Swimming Platform
Equipment & Outfitting Fin Stabilizing System: SLEIPNER:
Hydraulic Operated, Zero Speed Functionality
Air Conditioning System: WEBASTO:
180.000 BTU Chilled Water Compressor Unit, 380V AC, Heat & Cool Fan Coils in each guest cabins, salon and crew quarters Fresh Air Make-up Unit Volumes to be Air Conditioned; Main Deck Salon, Upper Deck Salon, All Guest & Crew Cabins, Wheelhouse, Galley, Crew Mess, Lazarette Air-Conditioned Spaces are Mechanically Ventilated
Wastewater Treatment System: TECNICOMAR:
Ecomar 20, Capacity 2 cbm / day
Vacuum Toilet System: JETS Electricity Extract Fan Ventilation in Toilets Water Maker: SEA RECOVERY:
Monitoring & Alarm Instruments Central Monitoring & Alarm System: MARETRON:
Touch Screen Display in Wheelhouse and Crew Quarter Monitoring of Tank Levels, Bilge Levels, Diesel Generators, Propulsion Engines, Main Switchboard Voltage (220VAC + 380VAC), Shore Power Voltage, Battery Levels, Navigation Lights
Camera Monitoring System: SONY:
5x 1080p IR, IP Cameras 8 Channel HD Camera Recorder 15” Led Display in Main Helm Bridge
Magnetic Compass, Barometer, Hydrometer kit Engines & Generators Digital Monitoring Indicators:
Shall also be Monitored in MARETRON AMS
Tank Level Monitoring Indicators:
Digital Indicators on Wheel Console Shall also be Monitored in MARETRON AMS
Bilge Level Alarms:
Visible & Audible Alarms Shall also be Monitored in MARETRON AMS
Accommodation Equipment Home Appliances for Galley: SIEMENS:
1x Washing Machine, 1x Dryer, 1x Ironing Mangle in Laundry: SIEMENS 1x Small Size Refrigerator in Flybridge Bar 1x Wine Coolers 1x Upper Deck Bar 3x Ice Cube Makers:
1x Upper Deck Bar, 1x Galley, 1x Flybridge Bar
LED TV’s: SAMSUNG:
65” Smart Flat UHD 4K in Main Deck Salon – Retractable 65” Smart Flat UHD 4K in Upper Deck Salon – Fixed on the Wall 55” Smart Flat UHD 4K in Owner’s Suite – Fixed on the Wall 40” Smart Flat UHD 4K in each cabin – Fixed on the Wall 40” Smart Flat UHD 4K in Crew Quarter – fixed on the wall
Home Theatre Sound System in Main Deck Salon Stereo System on Pool Deck & Flybridge
Watertight Upholstery with Sponge Fixed Wooden (Iroko) Table with Stainless Steel Leg Deck Bar with Cool Box
Fore Seating Area (if preferred by the Owner):
Watertight Upholstery with Sponge
Flybridge:
Control Station with Engines Throttle & Wheel Various Seating Groups & Watertight Upholstery with Sponge Grill & Bar House with Cool Box Sunbathing Area
Safety & Security Equipment
FM200 Fixed Fire Extinguishing System in Engine Room EPIRB + SART Emergency Beacons 2x Viking Life rafts On the Flybridge Deck Smoke Detection & Fire Alarm System in Engine Room Portable Fire Extinguishers in All Cabins Fire Blankets in Galley, Crew Lounge, Engine Room
Piping System & Pumps Fresh Water System:
Filling, supplying cold water and circulating hot water connected to the freshwater storage tank, water maker and water heater, equipped with LIVERANI or equivalent electric driven, Fresh Water Pressure Pumps and hot water circulation pumps, SS or Bronze ball valves. Hot water circulation pipelines are to be heat insulated. Capacity of the pumps as per calculations
Sanitary Drain & Discharge System:
Drainage of wastewater to the storage tanks and discharge the wastewater tank to Shore Connection on the aft deck and Wastewater Treatment Unit, equipped with electric driven, macerator pumps, SS or Bronze ball valves
Bilge Suction & Discharge System:
Suction and discharge of bilge water from each of watertight compartment separately equipped with two electric driven self-priming, centrifugal, bronze pumps, SS or Bronze ball valves Water level gauges are to be provided with audible and visible alarm on main helm bridge
Water Fire Extinguishing System & Nozzles:
Supplying sea water from sea chests to deck fire nozzles to the fire chests equipped with electric driven, centrifugal, Bronze, emergency pump, SS or Bronze ball valves
Fuel Filling & Supply & Transfer System:
Filling fuel tanks and supplying fuel to the consumers and return lines to the tanks, transferring the fuel between storage tanks or outside shore connection by means of electricity driven fuel transfer pump and air ventilation of the fuel storage tanks Double Racor or equivalent filters for each fuel consumer on fuel supply lines
Sea Water Cooling System:
A Central CuNiFe pipe system connected to two bottom sea chests in engine room with SS or Bronze butterfly valves and sea water strainers Engines, generators, and other consumers are to be cooled with sea water supply via branch lines connected to central sea water cooling pipe. Consumer’s connection are to be made with Neoprene flexible hoses
Hydraulic System:
Central hydraulic system is to consist of center power unit with electricity driven pump and PTO pumps on the main propulsion engines, seamless steel pipelines to operate bow thruster, anchor winches, capstans. Equipment is to be connected to the system with high pressure flexible hoses
Main Engines & Generators Exhaust System:
Water cooled, Heat Insulated Main Engines exhaust pipes made of mild steel Muffler Exhaust System for Gensets
Air Conditioning System:
Chilled water circulation to fan coils and water drain from fan coils to the tanks with polypropylene pipe lines. Chilled water circulation pipelines are to be heat insulated.
Electricity Electricity Power Supply:
24V DC loads to be supplied via dedicated battery banks and with own battery charger/supply units 230V 1-phase & 400V 3-phases 50Hz AC Power Generation from Generators 400V 3-phases AC Power Supply Shore Connection
Battery Groups: VICTRON or MASTERVOLT or Equivalent:
Marine Gel Service Batteries AGM Deep Cycle Engine Start Batteries AGM Deep Cycle Generator Start Batteries Marine Gel Emergency Batteries
Power Generator Plants:
2x 60 Kw, 400VAC 50Hz Marine Diesel Generator: KOHLER or equivalent Power Management System for all 2 generators to operate automatically Sound shields will be provided Note for Generator Capacities: Generator Capacities may be increased as per Owner’s requirements and is subject to price increase
Inverters & Battery Chargers: VICTRON or MASTERVOLT or equivalent:
Adequate Capacity Battery Charger Groups
24V DC / 230V AC / 400V AC Switchboards, Distribution Boxes & Fuses Accommodation Accommodation Lighting, Interior & Exterior:
Please Note: Optional Features Upgrade may extend the delivery time frame.
Delivery Delivery Time: 20 Months Boat Shall be Delivered as Seaworthy Condition at the Free Zone’s Quay in Antalya
Classification Built to B.V. Pleasure Yacht Commercial Classification available upon request
Comments Gilman Yachts is the AvA appointed dealer for AvA Shipyard of Antalya, Turkey for North and South America and the outlying islands. Having finished a 110’ Kando series at the shipyard, we offer experience with the brand, the shipyard and the ownership of the yard. Projects are delivered at very favorable price FOB Antalya and built to suit the electrical requirements of the buyer. Completion time on KANDO 90 is 18 months from contract signing.
Other Expenses at Owner's Account Non-Fixed, Loose Interior Decoration Components
Chairs, Dishes, Fork, Knife, Linens, etc.
Flag Registration Expenses & Taxes Tender Boat / Rescue Boat
Warranty Terms & Conditions The BUILDER, for a period of 12 months following acceptance of the YACHT by the BUYER, undertakes to repair and rectify at its own cost and expense and free of charge to the BUYER, any defects - including latent defects or deficiencies - concerning the YACHT or parts thereof, which are caused by defective material and/or poor workmanship on the part of the BUILDER, its servants, employees or Subcontractors, but excluding defects arising after delivery due to normal wear and tear or improper handling of the YACHT or caused or aggravated by omission or improper use or maintenance of the YACHT on the part of the BUYER, its servants or agents and excluding BUYER’s Supplies. The repairs, replacements and/or rectifications shall be made at the BUILDER's yard. However, the BUYER may, after having notified the BUILDER in writing, cause the necessary repairs, replacements and/or rectifications to be carried out elsewhere provided that the BUILDER declares its consent to do so. In such case, the BUILDER shall, at its own cost, be entitled to forward necessary replacement parts or materials. The BUILDER's liability shall in such case be limited to pay the cost of repairs, including travelling and forwarding expenses, to the price of the work which the BUILDER would normally charge at its yard. In any case, the BUILDER shall co-operate with the BUYER to find proper solutions to rectify the deficiency.
Disclaimer The company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change or withdrawal without notice. This 2026 Ava Yachts KANDO 90 Explorer Superyacht is listed for sale in Antalya,, Antalya. With a 90ft layout, inboard engine setup and new condition, this boat is suited to buyers looking for power options in this location. View full details, photos and specifications for reference RB573842 on Rightboat.
Details
ManufacturerAva Yachts
ModelKANDO 90 Explorer Superyacht
Year (Build / Refit)2026
Length27.4m
Total Power450 hp
Beam7.2m
Specifications
Dimensions
Length27.4m
Max Draft2.3m
Beam7.2m
Hull
MaterialSteel
Weight
Gross Tonnage250.00 GT
Displacement500.0 t
Dry Weight500.0 t
Accommodation
Guest Cabins6
Berths2
Bathrooms7
Features
Autopilot
Compass
Depth Instrument
GPS
Navigation Lights
Plotter
Radar
VHF
Anchor
Battery
Battery Charger
Bow Thruster
Generator
Gyroscopic Stabilizer
Windlass
Dishwasher
Fridge
Grill
Heating
Hob
Microwave
Oven
Watermaker
TV
Bilge Pump
Fire Extinguisher
Propulsion
Engine 1
Engine MakeVolvo Penta
Engine ModelD13
Drive TypeInboard Direct-Drive
Fuel TypeDiesel
Power450 hp
