Engine(s)
VOLVO D13-MH is a reliable, powerful, fuel-efficient and clean
marine diesel engine. It´s based on Volvo Group´s
proven engine platform and is designed by Volvo Penta
to power a wide range of marine auxiliary applications.
This 13 litre turbocharged diesel engine has a robust and
dependable design with an overhead camshaft, four valves
per cylinder and precisely controlled electronic fuel injection.
It features Volvo Group´s proven combustion technology which
creates an optimized fuel to air pressure ratio at any work load.
Together with Volvo Group´s Engine Management System it
offers powerful response, fuel efficiency and excellent emission
performance. The robust cylinder block is fitted with a
ladder frame for smooth operation and low noise.


• Proven design - built on Volvo Group technology
• Fuel-efficient and low emission levels
• High load acceptance
• Low weight, noise and vibrations
• Type-approved
• Classifiable by all major societies
• Compact installation and easy to service
The engine can be equipped with a wide range of optional
equipment and is available with Heat Exchanger (HE) or Keel
Cooled (KC) cooling system. Two options for on-board electronic
control: The type-approved MCC (Marine Commercial
Control) or Open Can Interface. The engine and equipment
can be covered with the Extended Coverage which prolongs
the standard warranty up to five years - or the corresponding
number of running hours

ZF W325
Description

Robust design also withstands continuous duty in workboat applications .

Fully works tested, reliable and simple to install .

Design, manufacture and quality control standards comply with ISO 9001 .

Reverse reduction marine transmission with hydraulically actuated multi-disc clutches .

Compatible with all types of engines and propulsion systems .
Features

Case hardened and precisely ground gear teeth for long life and smooth running .

Compact, space saving design .

Output shaft thrust bearing designed to take maximum propeller thrust astern and ahead .

Smooth and reliable hydraulic shifting with control lever for attachment of push-pull cable .

Suitable for twin engine installations (same ratio and torque capacity in ahead or astern mode) .

Replaceable oil filter cartridge .

Durable cast iron construction .
Options

Engine-matched torsional coupling .

Propeller shaft flange and coupling bolt sets .

Classification by all major Classification Societies on request .

Oil cooler complete with fittings and flexible oil hoses .

Trolling valve for slow-speed drive .

PTO’s (live or clutchable - retrofittable) .

SAE 1 bell housing .

Mounting brackets for rigid connection to foundation .

CUMMINS ONAN 35kw

The Cummins Onan Digital Display provides user-friendly diagnostics including extensive engine and alternator information and more
Largest worldwide certified Distributor/Dealer support network in the industry
The optimized mounting system greatly reduces vibration
Electronic frequency control - a must for digital appliances and computers requiring quality power
Cummins Onan marine generator sets are emissions certified to U.S. Environmental Protection Agency (EPA) Tier II emission standards
More than 70 years of marine experience stand behind every Cummins Onan Marine generator set



Twin VOLVO D13 600Hp@1900rpm

ZF W325 Gearbox

Cummins Onan 30kW
