EVOLUTION 40 LAUNCHING 2025

Evolution is an Instant Classic featuring an elegant and low profile design. A truly tri-deck pocket superyacht.

Horacio Bozzo

MAIN DIMENSIONS:

Length Overall 40.50 m (132’ 11")

Length waterline 39.50 m (129’ 06")

Breadth (Max) 8.00 m (26’03") Dive 2.30 m (07’06")

Estimated Gross Tonnage 410 GT

TANKS CAPACITY:

Fuel oil 50.000 lts. (13.200) gals

Fresh water 10.000 lts. (2.640) gals

Grey Water 3.500 lts. (925) gals

Black Water 3.500 lts. (925) gals PROPULSION

Main Engines 2 x Caterpillar C18 ACERT 599 kW 2100 rpm

Main generators 2 x 80 ekW

SPEED:

14 knots at max power and half load displacement RANGE 4200 nm at 10.0 knots

The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.

EVOLUTION 40 m

Twin-Screw Displacement Motor Yacht

MAIN DIMENSIONS

Length Overall

40.50 M (132’ 11”)

Length at Waterline 39.50 M (129’ 06”)

Breadth 8.00 M (26’03”)

Design Draft 2.30 M (07’06”)

Estimated Gross Tonnage 410 GT

TANKS CAPACITY

Fuel Oil

50,000 lts. (13,200) gallons

Fresh Water 10,000 lts. (2,640) gallons

Grey Water 3,500 lts. (925) gallons

Black Water 3,500 lts. (925) gallons

PROPULSION

Main Engines 2 x Caterpillar C18 ACERT 599 kW @ 2100 rpm

POWER GENERATION

Main Generators 2 x 80 ekW

SPEED

14 knots at max power and half load displacement

RANGE

4200 nm at 10.0 knots

BUILDING MATERIAL

Hull:

High Strength Steel Grade AH 36

Superstructure:

Aluminum Alloy 5083 H321 / H111

CLASSIFICATION

Lloyd's Register 100A1 SSC, Yacht, Mono, G6 [] LMC – Unrestricted navigation, LY3 Compliance

EXTERIOR DESIGN

HORACIO BOZZO DESIGN

NAVAL ARCHITECT

AXIS GROUP DESIGN
